TOMUU U6C Electric Linear Actuator For Recliner Headrest Lift Mechanism
| Continuous Current(A): | 4.0 أ | Efficiency: | آي إي 1 |
| Commutation: | فرشاة | Construction: | المغناطيس الدائم |
| Torque: | الطلبات | Type: | السيارات والعتاد |
| Usage: | أثاث | Warranty: | 3 أشهر ~ 1 سنة |
| Rated Voltage: | 12VDC / 24VDC | Max. load: | 2500N |
| Stroke: | 0-800 مم حسب الطلب | Speed: | 8-25 مم/ثانية عند عدم التحميل |
| Protection class: | IP65 | Duty cycle: | 10% |
| Limit switch: | محددة مسبقا | Position Feedback: | جهاز استشعار القاعة |
| High Light: | electric linear actuator for recliner,headrest lift mechanism actuator,furniture linear actuator with warranty,headrest lift mechanism actuator,furniture linear actuator with warranty |
||
| Parameter | Specification |
|---|---|
| Voltage | 12V DC / 24V DC |
| Max Load | 2500N |
| Speed | 8-25mm/s |
| Duty Cycle | 10% |
| Protection Class | IP65/IP66/IP67 |
| Noise Level | ≤52dB |
| Stroke | 50-800mm |
| Material | Aluminium Alloy |
- Customizable stroke length options to match specific application requirements
- Low heat dissipation motor design for enhanced reliability and longevity
- IP54 protection level against dust and water splash
- Precise angle positioning for headrest adjustment
- Wear-resistant metal gearbox extends service life
- Reduced maintenance costs for furniture manufacturers and end users
- Compatible with various recliner and lift chair internal transmission structures
